NORTH GNSS Receiver THOR III RTK 1288

Brand: NORTH
Model No.: THOR III RTK
Number of Channels: 1288
GPS Tracking Signal: L1 CA, L1/L2 P-code, L2C
Glonass Tracking Signal: L1/L2 CA, L1/L2 P-code
Sbas Tracking Signal: WAAS, EGNOS, MSAS, QZSS
Beidou Tracking Signal: B1,B2
Galileo Tracking Signal: E1, E5a, E5b, AltBOC, E6**
Positioning Rate: 5Hz, 20Hz
Static Receiver Accuracy H/V: Horizontal ± 2.5 mm + 0.5 ppm
Static Long Accuracy H/V: Vertical ± 5 mm + 0.5 ppm RMS
Kinematic Accuracy H/V: Horizontal ± 8 mm + 1 ppm RMS
GSM/GPRS Module: Vertical ± 15 mm + 1 ppm RMS
Bluetooth: Device class II
Communication Port: USB, serial and power
Keyboard: On/off and function keys
LED Status And Mode Indicators: 2
Data Recording: 8 GB removable microSD card
GSM/ TCP / IP: Removable SIM card
Material of Construction: Reinforce Nylon
Operating Time (Static/Rover): 7.5 h / 5 h
Protection Class: IP68 dust and waterproof
Operating Temperature: 40°C to 65°C
Humidity: 100%, condensing
Shock: IP67
Vibration: Designed to survive a 2 m
TNC Connector: UHF antenna, UMTS/GSM antenna
Uhf Radio Module: 2W UHF
Certification: R&TTE CE Mark
Weight: 1.2 kg
Dimension: 13 x 13 x 10 cm
