LOOM SOLAR Fusion 103 10 kW Three Phase String On Grid Solar Inverter

Brand: LOOM SOLAR
Anti Islanding Protection: Yes
Communication: Wifi,GPRS,RS485, 232,ETHERNET
DC Reverse Polarity Protection: Yes
Dimensions: 330 x 472 x 202 mm
Display Type: LCD
Earth Fault Protection: Yes
Ingress Protection: IP65
Maximum Efficiency: 98.5 %
Maximum Input Current: 20 A
Maximum Output Current: 15.9 A
Maximum PV Input Power: 13 kW
Maximum PV Input Voltage: 1000 V
Model: Fusion 103
Number of MPPT Tracker: 2
Operating Temperature: -25 to 65 deg. C
Over Current Protection: Yes
Over Temp Protection: Yes
Over Voltage Protection: Yes
Phase: Three Phase
Rated Output Power: 10 kW
Rated Output Voltage: 320 – 480 V
Startup Voltage: 140 V
Type of Inverter: String
Weight: 15 kg
